18-24
Measure Commands
HISTogram:HITS?
The query returns the measured frequency.
Returned Format [:MEASure:FREQuency] <value>[,<result_state>]<NL>
<value> is the frequency value, in Hertz, of the first complete cycle on the screen using the
mid-threshold levels of the waveform. If SENDvalid is ON, the <result_state> is returned with
the measurement result. Refer to Table 18-4 on page 18-39 for a list of the result states.
Example 10 OUTPUT 707;”:MEASURE:FREQUENCY”
HISTogram:HITS?
Query :MEASure:HISTogram:HITS? [{HISTogram}]
Returns the number of hits within the histogram. The source can be specified with the
optional parameter following the HITS query. The HISTogram:HITS? query only applies to the
histogram.
Returned Format [:MEASure:HISTogram:HITS] <value>[,<result_state>]<NL>
<value> is the number of hits in the histogram. If SENDvalid is ON, the <result_state> is
returned with the measurement result. Refer to Table 18-4 on page 18-39 for a list of the
result states.
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MEASURE:HISTOGRAM:HITS?”
HISTogram:M1S?
Query :MEASure:HISTogram:M1S? [{HISTogram}]
Returns the percentage of points that are within one standard deviation of the mean of the
histogram. The source can be specified with the optional parameter following the M1S query.
The HISTogram:M1S? query only applies to the histogram waveform.
Returned Format [:MEASure:HISTogram:M1S] <value>[,<result_state>]<NL>
<value> is the percentage of points within one standard deviation of the mean of the histo-
gram. If SENDvalid is ON, the <result_state> is returned with the measurement result. Refer
to Table 18-4 on page 18-39 for a list of the result states.
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MEASURE:HISTOGRAM:M1S?”
HISTogram:M2S?
Query :MEASure:HISTogram:M2S? [{HISTogram}]
Returns the percentage of points that are within two standard deviations of the mean of the
histogram. The sources can be specified with the optional parameter following the M2S
query. The HISTogram:M2S? query only applies to the histogram waveform.
Returned Format [:MEASure:HISTogram:M2S] <value>[,<result_state>]<NL>
<value> is the percent of points within two standard deviations of the mean of the histogram.
If SENDvalid is ON, the <result_state> is returned with the measurement result. Refer to
Table 18-4 on page 18-39 for a list of the result states.
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MEASURE:HISTOGRAM:M2S?”
