19-4

S-Parameter Commands

MAGGraph:VERTical:MAXimum

Sets the frequency span of the S-parameters graph.

Example 10 OUTPUT 707;":SPAR:MAGG:HOR:SPAN 5.0E+9"

Query :SPARameter:MAGGraph:HORizontal:SPAN?

Returned Format [:SPARameter:MAGGraph:HORizontal:SPAN] <span_freq><NL>

MAGGraph:VERTical:MAXimum

Command :SPARameter:MAGGraph:VERTical:MAXimum <vertical_max>

Sets the maximum amplitude (dB) of the S-parameters graph.

Example 10 OUTPUT 707;":SPAR:MAGG:VERT:MAX 5"

Query :SPARameter:MAGGraph:VERTical:MAXimum?

Returned Format [:SPARameter:MAGGraph:VERTical:MAXimum] <vertical_max><NL>

MAGGraph:VERTical:MINimum

Command :SPARameter:MAGGraph:VERTical:MINimum <vertical_min>

Sets the minimum amplitude (dB) of the S-parameters graph.

Example 10 OUTPUT 707;":SPAR:MAGG:VERT:MIN -30"

Query :SPARameter:MAGGraph:VERTical:MINimum?

Returned Format [:SPARameter:MAGGraph:VERTical:MINimum] <vertical_min><NL>

MARKer:X1STate

Command :SPARameter:MARKer:X1STate {ON | 1 | OFF | 0}

Turn on and off the X1 marker.

Example 10 OUTPUT 707;":SPAR:MARK:X1ST ON"

Query :SPARameter:MARKer:X1STate?

Returned Format [:SPARameter:MARKer:X1STate] {ON | 1 | OFF | 0}<NL>

MARKer:X2STate

Command :SPARameter:MARKer:X2STate {ON | 1 | OFF | 0}

Turn on and off the X2 marker.

Example 10 OUTPUT 707;":SPAR:MARK:X2ST ON"

Query :SPARameter:MARKer:X2STate?

Returned Format [:SPARameter:MARKer:X2STate] {ON | 1 | OFF | 0}<NL>

MARKer:X1Source

Command :SPARameter:MARKer:X1Source {CHANnel<N> | RESPonse<N> | WMEMory<N> | FUNCtion<N>}

Selects the source waveform of the X1 marker, if more than one waveform is displayed on the

graph.

Example 10 OUTPUT 707;":SPAR:MARK:X1S CHAN2"
