5-6
Hardkey/Softkey Reference
Analyzer Functions
selects the 85056K cal kit.
selects the 2.92 mm cal kit model.
selects the 85033C cal kit.
selects the 85033D or the 85033E cal kit.
sets up a four-graticule display with channel 2 in the
upper right quadrant and channel 3 in the lower left
quadrant.
sets up a four-graticule display with channel 3 in the
upper right quadrant and channel 2 in the lower left
quadrant.
provides single-keystroke options to quickly set up
multiple-channel displays, and information on
multiple-channel displays.
selects the 85038A/F/M cal kit.
selects the 85031B cal kit.
measures the absolute power amplitude at input A.
calculates and displays the complex ratio of input A to
input B.
is displayed during ECal dual module operation and
during manual thru operation as a pause in the process of
measurement. Press this softkey to stop the process and
return to the main ECal menu.
calculates and displays the complex ratio of the signal at
input A to the reference signal at input R.
puts the name of the active entry in the display title.
puts the active marker magnitude in the display title.
selects coaxial as the type of adapter used in adapter
removal calibration.
selects waveguide as the type of adapter used in adapter
removal calibration.
is used to enter the value of electrical delay of the adapter
used in adapter removal calibration.
provides access to the adapter removal menu.
1) displays the edit segment menu and adds a new
segment to the end of the list. The new segment is initially
a duplicate of the segment indicated by the pointer > and
selected with the softkey.
