7-7
Options and Accessories
Accessories Available
RF electronic calibration (ECal) modules and PC software
This product family provides electronic calibration (ECal) capability. With ECal, the usual
calibration kit standards are replaced by one solid-state calibration module. A full two-port
calibration can be done with a single connection, with reduced errors and wear on
connectors. ECal requires the 85097A/B PC interface kit, an 85090-series calibration
module with the appropriate connector type, and a network analyzer with firmware
version 7.68 and above.
NOTE For network analyzers with firmware versions between 7.60 and 7.68, a PC
with Windows
1
95, 98, 2000 or NT 4.0 loaded with software from the
85097A/B PC interface kit is used to perform the ECal calibration.
• 85097A/B ECal PC interface kit and software
— Contains PC interface module for connecting an ECal module to a PC or a network
analyzer (with firmware version 7.68 and above) and PC ECal control software.
• 85091B RF ECal module (30 kHz to 9 GHz), 7-mm connectors
• 85092B RF ECal module (30 kHz to 9 GHz), 50 Ω type-N (m) to 50 Ω type-N (f)
connectors
— Option 00F substitutes type-N (f) to type-N (f) RF ECal module.
— Option 00M substitutes type-N (m) to type-N (m) RF ECal module.
— Option 00A adds:
— type-N (f) to type-N (f) adapter
— type-N (m) to type-N (m) adapter
• 85093B RF ECal module (30 kHz to 9 GHz), 3.5-mm (m) to 3.5-mm (f) connectors
— Option 00F substitutes 3.5-mm (f) to 3.5-mm (f) RF ECal module.
— Option 00M substitutes 3.5-mm (m) to 3.5-mm (m) RF ECal module.
— Option 00A adds:
— 3.5-mm (f) to 3.5-mm (f) adapter
— 3.5-mm (m) to 3.5-mm (m) adapter
• 85098B RF ECal module (30 kHz to 7.5 GHz), 7-16 (m) to 7-16 (f) connectors
— Option 00F substitutes 7-16 (f) to 7-16 (f) RF ECal module.
— Option 00M substitutes 7-16 (m) to 7-16 (m) RF ECal module.
— Option 00A adds:
— 7-16 (f) to 7-16 (f) adapter
— 7-16 (m) to 7-16 (m) adapter
1. Windows is a U.S. registered trademark of Microsoft Corporation.
