Options and Accessories
Accessories Available
• 85096B RF ECal module (30 kHz to 3 GHz), 75 Ω type-N (m) to 75 Ω type-N (f)
connectors
— Option 00F substitutes module with two type-N female connectors.
— Option 00M substitutes module with two type-N male connectors.
— Option 00A adds:
— type-N (m) to type-N (m) adapter
— type-N (f) to type-N (f) adapter
• 85099B RF ECal module (30 kHz to 3 GHz), 75 Ω type-F (m) to type-F (f) connectors
— Option 00F substitutes module with two type-F female connectors.
— Option 00M substitutes module with two type-F male connectors.
— Option 00A adds:
— type-F (m) to type-F (m) adapter
— type-F (f) to type-F (f) adapter
• N4431A 4-Port RF ECal module (300 kHz to 9 GHz)
— Option 010 provices for all four ports with 3.5-mm (f) connectors.
— Option 020 provides for all four ports with Type-N 50Ω (f) connectors.
— Option UK6 adds commercial calibration certificate with measured data.
— Mixed Connector Options.
Table 7-1 N4431A Mixed Connector Options
Connector Type Port A Option Port B Option Port C Option Port D Option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50Ω (f) 103 203 303 403
Type-N 50Ω (m) 104 204 304 404
7-16 (f)
a
a. Limits ECal module high frequency to 7.5 GHz
105 205 305 405
7-16 (m)
a
106 206 306 406
