5-17
Hardkey/Softkey Reference
Analyzer Functions
leads to the define print menu. This menu defines the
printer mode (monochrome or color) and the auto-feed
state.
makes the standard number the active function, and
brings up the define standard menus. The standard
number (1 to 8) is an arbitrary reference number used to
reference standards while specifying a class.
selects the group delay format, with marker values given
in seconds.
defines the standard type as a transmission line of
specified length, for calibrating transmission
measurements.
deletes the segment or the frequency band indicated by
the > pointer.
deletes all files.
deletes a selected file.
sets the limits an equal amount above and below a
specified middle value, instead of setting upper and lower
limits separately. This is used in conjunction with
or , to set limits
for testing a device that is specified at a particular value
plus or minus an equal tolerance.
For example, a device may be specified at 0 dB ±3 dB.
Enter the delta limits as 3 dB and the middle value as
0dB.
(Option 010 only) amplitude demodulation for CW time
transform measurements.
(Option 010 only) turns time domain demodulation off.
(Option 010 only) phase demodulation for CW TIME
transform measurements.
lets you specify the number of directory files to be
initialized on a disk. This is particularly useful with a
hard disk, where you may want a directory larger than the
default 256 files, or with a floppy disk you may want to
reduce the directory to allow extra space for data files. The
number of directory files must be a multiple of 8. The
minimum number is 8, and there is no practical maximum
limit. Set the directory size before initializing a disk.
→
