Agilent Technologies 8753ES Reference Guide

5-19
Hardkey/Softkey Reference
Analyzer Functions
finishes one-port calibration (after all standards are
measured) and turns error correction on.
finishes two-port calibration (after all standards are
measured) and turns error correction on (ES only).
finishes the transmission portion of the enhanced response
calibration.
finishes all the load standards when the cal kit defines
more than one load standard.
finishes all the open standards when the cal kit defines
more than one open standard.
finishes all the short standards when the cal kit defines
more than one short standard.
finishes response and isolation calibration (after all
standards are measured) and turns error correction on.
finishes the transmission portion of the enhanced response
calibration. (ES only)
terminates the sequencing edit mode.
finishes TRL/LRM two-port calibration (after all
standards are measured) and turns error correction on.
sets the analyzer's source higher than the analyzer's
receiver for making measurements in frequency offset
mode.
toggles between the displayof both measurement channels
or the active channel only. This is used in conjunction with
in the display
menu to display multiple
channels. With the two traces are
overlaid on a single graticule.
activates a sub-menu of , which allows you to
enable the auxiliary channels and configure
multiple-channel displays.
duplicates a sequence currently in memory into a different
softkey position. Duplicating a sequence is
straightforward. Follow the prompts on the analyzer
screen. This command does not affect the original
sequence.
DONE 1-PORT CAL
DONE 2-PORT CAL
DONE FWD ENH RESP.
DONE LOADS
DONE OPENS
DONE SHORTS
DONE RESP ISOL'N CAL
DONE REV ENH RESP.
DONE SEQ MODIFY
DONE TRL/LRM
DOWN CONVERTER
DUAL CH on OFF
SPLIT DISP 1X 2X 4X
DUAL|QUAD SETUP
SPLIT DISP 1X
DUAL|QUAD SETUP
Display
DUPLICATE SEQUENCE
