6-8
Error Messages
Error Messages in Alphabetical Order
CORRECTION TURNED OFF
Error Number
66
Critical parameters in your current instrument state do not match the
parameters for the calibration set, therefore correction has been turned off. The
critical instrument state parameters are sweep type, start frequency, frequency
span, and number of points.
CURRENT PARAMETER NOT IN CAL SET
Error Number
64
Correction is not valid for your selected measurement parameter. Either change
the measurement parameters or perform a new calibration.
D2/D1 INVALID WITH SINGLE CHANNEL
Error Number
130
You can only make a D2/D1 measurement if both channels are on.
D2/D1 INVALID: CH1 CH2 NUM PTS DIFFERENT
Error Number
152
You can only make a D2/D1 measurement if both channels have the same
number of points.
DEADLOCK
Error Number
111
A fatal firmware error occurred before instrument preset completed. Call your
local Agilent Technologies sales and service office.
DEMODULATION NOT VALID
Error Number
17
Demodulation was selected when the analyzer was not in CW time mode. Select
demodulation only after putting the analyzer into CW time mode.
DEVICE: not on, not connect, wrong addrs
Error Number
119
The device at the selected address cannot be accessed by the analyzer. Verify
that the device is switched on, and check the GPIB connection between the
analyzer and the device. Ensure that the device address recognized by the
analyzer matches the GPIB address set on the device itself.
DIRECTORY FULL
Error Number
188
There is no room left in the directory to add files. Either delete files or get a new
disk.
DISK HARDWARE PROBLEM
Error Number
39
The disk drive is not responding correctly. Refer to the service guide for
troubleshooting information. If using an external disk drive, refer to the disk
drive operating manual.
