6-11
Error Messages
Error Messages in Alphabetical Order
ECal: SELECT OTHER MODULE
Error Number
221
This error occurs when two ECal modules are connected. The selected ECal
module may not be able to measure the selected frequency range. Check the
frequency range of the other module and connect in the RF path.
ECal: THRU STATE
Information
Message
This message is displayed when the ECal module is set to the thru state.
EXCEEDED 7 STANDARDS PER CLASS
Error Number
72
When modifying calibration kits, you can define a maximum of seven standards
for any class.
EXTERNAL SOURCE MODE REQUIRES CW TIME
Error Number
148
An external source can only be phase locked and measured in the CW time
sweep mode.
EXT SOURCE NOT READY FOR TRIGGER
Error Number
191
There is a hardware problem with the 8625A external source. Verify the
connections between the analyzer and the external source. If the connections are
correct, refer to the source operating manual.
EXT SRC: NOT ON/CONNECTED OR WRONG ADDR
Error Number
162
The analyzer is unable to communicate with the external source. Check the
connections and the GPIB address on the source.
FILE NOT COMPATIBLE WITH INSTRUMENT
Information
Message
You cannot recall user graphics that had been saved on an earlier model of
analyzer with a monochrome display. These files cannot be used with the
analyzer.
FILE NOT FOUND
Error Number
192
The requested file was not found on the current disk medium.
FILE NOT FOUND OR WRONG TYPE
Error Number
197
During a recall operation, either the file was not found or the type of file was not
an instrument state file.
