6-23
Error Messages
Error Messages in Alphabetical Order
SLIDES ABORTED (MEMORY REALLOCATION)
Error Number
73
You cannot perform sliding load measurements due to insufficient memory.
Increase the available memory by clearing one or more save/recall registers and
pressing , or by storing files to a disk and then deleting them from
internal memory.
SOURCE POWER DISABLED, EDIT LIST MODE TBL
Information
Message
When list power has been enabled and swept list mode is on, you will not be able
to change the power level using the key. To change the power level, edit
the swept list table.
SOURCE POWER TURNED OFF, RESET UNDER POWER MENU
Information
Message
You have exceeded the maximum power level at one of the inputs and power has
been automatically reduced. The annotation P⇓ indicates that power trip has
been activated. When this occurs, reset the power and then press
, to switch on the power.
STARTING COPY SPOOLER
Information
Message
The analyzer is beginning to output data from the spool buffer to the copy
device. The analyzer resumes normal operation; the data is being output to the
copy device in the background.
STOP/CW FREQ + OFFSET MUST BE < 3 GHz
Error Number
141
The output frequency of the mixer cannot violate the minimum/maximum
frequency of the analyzer.
SWEEP MODE CHANGED TO CW TIME SWEEP
Error Number
187
If you select external source auto or manual instrument mode and you do not
also select CW mode, the analyzer is automatically switched to CW.
SWEEP TIME INCREASED
Error Number
11
You have made instrument changes that cause the analyzer sweep time to be
automatically increased. Some parameter changes that cause an increase in
sweep time are narrower IF bandwidth, an increase in the number of points,
and a change in sweep type.
SWEEP TIME TOO FAST
Error Number
12
The fractional-N and digital IF circuits have lost synchronization. Refer to the
service guide for troubleshooting information.
Preset
Power
Power
