8-10
Preset State and Memory Allocation
Preset State
Printer Colors
Ch1/Ch3 Data Magenta
Ch1/Ch3 Mem Green
Ch2/Ch4 Data Blue
Ch2/Ch4 Mem Red
Graticule Cyan
Warning Black
Text Black
Reference Line Black
a. The directory size is calculated as 0.013% of the floppy disk size
(which is ≈256) or 0.005% of the hard disk size.
b. Pressing preset turns off sequencing modify (edit) mode and stops any running
sequence.
Table 8-2 Preset Conditions
Format Table Scale Reference
Position Value
Log Magnitude (dB) 10.0 5.0 0.0
Phase (degree) 90.0 5.0 0.0
Group Delay (ns) 10.0 5.0 0.0
Smith Chart 1.00 – 1.0
Polar 1.00 – 1.0
Linear Magnitude 0.1 0.0 0.0
Real 0.2 5.0 0.0
Imaginary 0.2 5.0 0.0
SWR 1.00 0.0 1.0
Table 8-1 Preset Conditions (Continued)
Preset Conditions Preset Value
