2-26
8753ET Specifications and Characteristics
Instrument Specifications
Table 2-24 Sweep Time vs. IF Bandwidth
IF Bandwidth
Typical Sweep Time (seconds)
a
a. Preset condition, CF = 1 GHz, Span = 100 MHz; includes retrace time, 201 points.
6000 0.070
3700 0.095
3000 0.121
1000 0.248
300 0.704
100 2.022
30 6.987
10 21.365
Table 2-25 Sweep Time vs. Number of Points
Number of Points
Typical Sweep Time (seconds)
a
a. Preset condition, CF = 1 GHz, Span = 100 MHz, Correction off; includes retrace time.
Measurement speed can be improved by selecting the widest IF bandwidth setting of 6000 Hz.
51 0.039
101 0.057
201 0.095
401 0.171
801 0.323
1601 0.625
