Agilent Technologies E3649A User Manual

206
Index
Index
A
AC input ratings 166
accessories 30
activation time 164
active load 36
annunciators, display 7
application programs 138
asterisk ( * ) 118
B
basic tests
output checkout 20, 21
preliminary checkout 19
battery charging 58
bus controller, interrupt 110
C
C programming example 139
calibration 67
disable security code 67
interval (recommended) 166
message (string) reading 71
calibration commands 98
character frame 64
checkout
current output 21
preliminary 19
voltage output 20
colon 117
command format 116
command separators
colon 117
semicolon 117
command syntax 116
commands(calibration)
CALibration:COUNt? 98
CALibration:CURRent 98
CALibration:CURRent:LEVel 98
CALibration:SECure:CODE 98
CALibration:SECure:STATe 99
CALibration:SECure:STATe? 99
CALibration:STRing 99
CALibration:STRing? 99
CALibration:VOLTage:LEVel 99
CALibration:VOLTage:PROTection
99
CALibration:VOLTage[:DATA] 99
commands(Interface Configuration)
<Ctrl-C> 101
SYSTem:INTerface 101
SYSTem:LOCal 101
SYSTem:REMote 101
SYSTem:RWLock 101
commands(output setting and
measurement)
APPLy 84
APPLy? 84
CURRent 85
CURRent:STEP 85
CURRent:STEP? 86
CURRent:TRIGgered 86
CURRent:TRIGgered? 86
CURRent? 85
INSTrument
COUPle[:TRIGger] 87
INSTrument:COUPle[:TRIGger]? 87
INSTrument:NSELect 86
INSTrument:NSELect? 87
INSTrument[:SELect] 86
INSTrument[:SELect]? 86
MEASure:CURRent? 87, 91
MEASure[:VOLTage]? 88
OUTPut:TRACk[:STATe] 88
OUTPut:TRACk[:STATe]? 88
VOLTage 88
VOLTage:PROTection 90
VOLTage:PROTection:CLEar 90
VOLTage:PROTection:STATe 90
VOLTage:PROTection:STATe? 90
VOLTage:PROTection:TRIPped? 90
VOLTage:PROTection? 90
VOLTage:RANGe 90
VOLTage:RANGe? 90
VOLTage:STEP 89
VOLTage:STEP? 89
VOLTage:TRIGgered 89
VOLTage:TRIGgered? 89
VOLTage? 88
commands(state storage)
*RCL { 1 | 2 | 3 | 4 | 5 } 97
*SAV { 1 | 2 | 3 | 4 | 5 } 97
MEMory:STATe:NAME { 1 | 2 | 3 | 4 |
5}
97
commands(status reporting)
*CLS 113
*ESE 113
*ESE? 113
*ESR? 114
*OPC 114
*OPC? 114
*PSC { 0 | 1 } 114
*PSC? 114
*SRE 114
*SRE? 114
*STB? 114
*WAI 114
STATus:QUEStionable:ENABle 112
STATus:QUEStionable:ENABle? 112
STATus:QUEStionable:INSTru-
ment:ENABle 112
STATus:QUEStionable:INSTru-
ment:ENABle? 112
STATus:QUEStionable:INSTru-
ment:ISUMmary<n>:CONDition?
113
STATus:QUEStionable:INSTru-
ment:ISUMmary<n>:ENABle 113
STATus:QUEStionable:INSTru-
ment:ISUMmary<n>:ENABle? 113
STATus:QUEStionable:INSTru-
ment:ISUMmary<n>[:EVENt]? 113
STATus:QUEStionable:INSTru-
ment[:EVENt]? 112
STATus:QUEStionable? 112
SYSTem:ERRor? 112
commands(system-related)
*IDN? 95
*RST 96
*TST? 95
DISPlay {OFF | ON} 94
DISPlay:MODE {VI | VV | II} 94
DISPlay:MODE? 94
DISPlay:TEXT 94
DISPlay:TEXT:CLEar 94
DISPlay:TEXT? 94
DISPlay? 94
OUTPut {OFF | ON} 94
OUTPut:RELay {OFF | ON} 95
OUTPut:RELay? 95
OUTPut? 94
SYSTem:BEEPer 95
SYSTem:ERRor? 95
SYSTem:VERSion? 95
commands(triggering)
*TRG 93
INITiate 93
TRIGger:DELay 93
TRIGger:DELay? 93
TRIGger:SOURce 93
TRIGger:SOURce? 93
common commands (IEEE-488.2) 118
common mode current noise 155
connection to a computer or terminal
DB-25 Serial Connection 66
DB-9 Serial Connection 65
GPIB connector 63
connections(power supplies)
parallel connections 157
series connections 157
connector
GPIB 63
RS-232 (serial) 64
constant current (CC) mode 153, 154
constant current operation 44, 45
constant voltage (CV) mode 153, 154
constant voltage operation 42, 43
cooling 33, 166
coupling effects 38
