Hardkey and Softkey Reference ESG Family Signal Generators
Frequency
4-38 User’s Guide
Frequency
Press this front panel hardkey to change the RF output frequency.
Frequency becomes the active function and the current value is also
shown in the active entry area of the display. To enter a new value for
frequency, rotate the front panel knob until the desired value is
displayed, use the up and down arrow keys, or enter the value using the
numeric keypad and press the
GHz, MHz, kHz, or Hz terminator softkey.
The output frequency range allowed depends on your instrument
model. Refer to the technical specifications document.
The current RF output frequency is always shown in the frequency area
of the display (unless you have altered the display by turning on
frequency reference mode or entering an offset or a multiplier). The
frequency area of the display is blanked whenever a frequency sweep is
selected.
Default Value: Maximum specified output frequency
