ESG Family Signal Generators Memory Structure
File Storage – the Memory Catalog
User’s Guide 5-3
File Storage – the Memory Catalog
The signal generator’s interface
for stored files is the memory
catalog. You can view, copy,
rename and delete files from the
memory catalog either from the
instrument’s front panel or
remotely (for information on
performing these tasks remotely,
see the programming guide).
The Default catalog subcatalogs
contain the following information:
Binary
User files, and any
other binary files
downloaded to the signal generator.
Bit User file data created/modified using the bit editor or downloaded to the signal generator.
Bit files contain a 10-byte header.
FIR Finite impulse response filter files that contain coefficient values.
List Data associated with frequency and amplitude sweeps, such as frequency start/stop, dwell
time, sweep type/repeat/trigger, point trigger, mode, direction, and trigger out polarity.
Shape Data associated with specifying burst shape.
State Data controlling instrument operating state parameters, such as frequency, power level,
and mode.
NOTE ARB catalog files and Modulation catalog files are documented in the
applicable option user’s and programming guide.
Viewing Stored Files
1. Press the Utility hardkey.
2. Press the softkey
Memory Catalog.
3. Press
Catalog Type. The default catalog type is All (files are listed in alphabetical order).
4. To view a specific catalog type, choose that catalog’s softkey.
NOTE Catalogs may display an additional menu of softkeys where you choose the
specific subcatalog that you wish to view.
Default Catalog
Subcatalogs
Binary
Bit
FIR
List
Shape
State
ARB Catalog
Subcatalogs
Used by
dual arbitrary waveform generator options
Modulation Catalog
Subcatalogs
Used by both
dual arbitrary waveform generator and
baseband generator options
