ESG Family Signal Generators Hardkey and Softkey Reference
Utility
User’s Guide 4-125
MDMOD
Press this softkey to set the current catalog type to MDMOD and
display the catalog of MDMOD files.
Softkey Location:
Utility > Memory Catalog > Catalog Type >
ARB Catalog Types > MDMOD
MDWCDMA
Press this softkey to set the current catalog type to MDWCDMA and
display the catalog of MDWCDMA files.
Softkey Location:
Utility > Memory Catalog > Catalog Type >
ARB Catalog Types > MDWCDMA
MFCDMA
Press this softkey to set the current catalog type to MFCDMA and
display the catalog of MFCDMA files.
Softkey Location:
Utility > Memory Catalog > Catalog Type >
ARB Catalog Types > MFCDMA
MFWCDMA
Press this softkey to set the current catalog type to MFWCDMA and
display the catalog of MFWCDMA files.
Softkey Location:
Utility > Memory Catalog > Catalog Type >
ARB Catalog Types > MFWCDMA
Modify License Key
Press this softkey to enter the license key for the highlighted software
option. Software options are linked to specific optional hardware that
must first be installed before the software option can be operational.
Adding new software options requires the use of a license key that is
provided by Agilent Technologies at the time of purchase. Once the
license key is entered, the software option will be enabled when you
press the
Proceed with Reconfiguration softkey. Refer to Chapter 2, “Using
Functions,” for an example of using this function.
CAUTION If you enable an option that does not have the required hardware
installed, the menus for that option will be activated but the option
cannot operate, despite what the menus may seem to indicate.
Softkey Location:
Utility > Instrument Adjustments > Software Options >
Modify License Key
