Downloading and Using Files
Introduction
Chapter 4146
Introduction
Computer generated data can be downloaded into your signal generator. Depending on the
options present, the signal generator will accept ARB waveform data, user file data, FIR filter
coefficient data, and data downloads directly to waveform memory. This section explains the
different download methods, and the data formatting required for each method.
This chapter is divided by data transfer method. In addition, there is a section providing
troubleshooting information:
“ARB Waveform Data Downloads” on page 147
“Downloading E443xB Signal Generator Files” on page 161
“User File Data Downloads” on page 167
“FIR Filter Coefficient Downloads” on page 179
“Downloads Directly into Pattern RAM (PRAM)” on page 183
“Data Transfer Troubleshooting” on page 189
