30
Power requirements 90 to 254 V; 50, or 60 Hz; 300 W maximum,
power factor corrected. Not for 400 Hz use.
1
Operating temperature range
2
0 to 55 °C
Storage temperature range –40 to 71 °C
Shock and vibration Meets MIL-STD-28800E Type III, Class 3.
Leakage Conducted and radiated interference meets
MIL-STD-461C CE02 Part 2 and CISPR 11. Leakage is
typically < 1 µV [nominally 0.1 µV with a 2-turn loop] at
≤ 1000 MHz, measured with a resonant dipole antenna,
one inch from any surface with output level < 0 dBm
[all inputs/outputs properly terminated].
Storage registers Memory is shared by instrument states, user data files,
non-volatile waveforms, sweep list files and waveform
sequences. There is 14 MB of flash memory standard in
the ESG. With Option 005, there is 6 GB of storage.
Depending on available memory, a maximum of 1000
instrument states can be saved.
Weight < 16 kg [35 lb.] net, < 23 kg [50 lb.] shipping
Dimensions 133 mm H x 426 mm W x 432 mm D
[5.25 in H x 16.8 in W x 17 in D]
Remote programming
Interface GPIB [IEEE-488.2-1987] with listen and talk, RS-232,
LAN [10BaseT].
Control languages
3
SCPI version 1996.0, also compatible with 8656B and
8657A/B/C/D/J1 mnemonics.
Functions controlled All front panel functions except power switch and knob.
ISO compliant The E4438C ESG is manufactured in an ISO-9001
registered facility in concurrence with
Agilent Technologies commitment to quality.
Reverse power protection
Standard With Option 506
250 kHz to 2 GHz 47 dBm 30 dBm
> 2 to 4 GHz 44 dBm 30 dBm
> 4 to 6 GHz N/A 30 dBm
Max DC voltage 50 V
SWR
4
Standard Option UNB Option 506
250 kHz to 2.2 GHz (< 1.5:1) (< 1.5:1) (< 1.6:1)
> 2.2 GHz to 3 GHz (< 1.4:1) (< 1.5:1) (< 1.4:1)
> 3 GHz to 4 GHz (< 1.5:1) (< 1.7:1) (< 1.7:1)
> 4 GHz to 6 GHz N/A N/A (< 1.8:1)
Output impedance 50 Ω nominal
General Characteristics
1. For 400 Hz systems, order transformer 70001-60066.
2. Save and recall of user files and instrument states from non-volatile storage is guaranteed only over the range 0 to 40 °C.
3. ESG series does not implement 8657A/B “Standby” or “On” [R0 or R1, respectively] mnemonics.
4. Parentheses denote typical performance.
Operating characteristics
