7
Remove the Instrument Covers
Tools Required
• T-10 driver
• T-15 driver
• T-20 driver
• Long-nose pliers
Remove the Outer Cover
Refer to Figure 1.
1. Disconnect the power cord.
2. Using a T-20 driver, remove the two strap handles (1) by loosening the screws.
3. Using a T-15 driver, remove the center screws (2) on the four rear-panel feet (3).
4. Remove the four bottom feet (4) and (5) from the cover by pushing and pulling the tab.
5. Slide the outer cover (6) off the frame.
Remove the Top Inner Cover
Refer to Figure 1.
1. Using a T-10 driver, remove the ten screws (8) from the inner cover (7).
2. Remove the inner cover.
