166 Chapter 8
Hardware Options
What You Will Find in This Chapter
What You Will Find in This Chapter
The following information is found in this chapter:
1. Procedures to verify the functionality of each option.
2. Block diagrams of each option.
This following descriptions are found in this chapter:
NOTE See “Instrument Hardware Option Descriptions” on page 16 for
overviews of Options 122 or 140, 123, and 124.
See Chapter 3 for information on:
• Option B7J, Digital Demod hardware
• Option 1DS, Lowband Preamplifier
• Option AYZ, External Mixing
• Option BAB, 3.5 mm input connector
Verifying Option 107 Audio Input page 167
Verifying Option 110 page 169
Verifying Option 122 or 140, Wide Bandwidth Digitizer page 174
Overview and Verification of Option 123, Microwave
and Millimeter Preselector Bypass
page 187
Verifying Option 124, Y-Axis Video Out page 203
