Agilent Technologies E4443A Service Guide

234 Chapter 10
Replaceable Parts Lists and Locations
Replaceable Parts
Display Pressure Plate E4406-00037 X X X X X X
Display Bezel Assembly
(includes left overlay
label, but does not
include nameplate)
E4440-60081 X X X X X X
Mid Web E4406-20109 X X X X X X
Spacer for switches
(Option 123)
0380-1402 X X X
Screw, M3 x 0.05 5.4 LG
for switch mounting
(Option 123)
0515-1715 X X X
Thermal Pad
(Option 123)
N1996-40018 X X X
Rivet, fan mounting0361-1272 XXXXXX
Fan Guard 3160-0281 XXXXXX
Rivet, fan guard
mounting
0361-1888 X X X X X X
Cable hold down
(on Midweb)
5022-6135 X X X X X X
Cable Clamp,
plastic, adhesive backed
(Option 110, 123)
1400-0611 X X X X X X
Cable Clip Sleeves
(numbers 0-9,
1 wand for each number,
each wand has
> 10 numbers)
7121-8265 X X X X X X
Bracket,
FIFA/cable restraint for
Lowband assembly
E4447-60001 X
Screw, M2.5 X 0.45,
6 MM, TORX
(Option 110, 123)
Attaches SW4 and SW5
to bracket
0515-1934 X X X
Screw, 2-56
.312 in, POZI
Attaches A36 P-Amp
to bracket
0520-0129 X X X
Table 10-2 Mechanical Parts
Description Part Number E4440A E4443A E4445A E4446A E4447A E4448A
