Chapter 4
Front-Panel Key and SCPI Command Reference
Measure
169
Front-Panel Key and SCPI Command
Reference
4.3.14 Audio SINAD
Allows the user to switch to the Audio SINAD measurement.
4.3.14.1 SCPI Remote Commands
:CONFigure:AUDSinad
:INITiate:AUDSinad
:FETCh:AUDSinad[n]?
:MEASure:AUDSinad[n]?
:READ:AUDSinad[n]?
Mode: MRECEIVE
Key Path:
Measure, More, More
Remote Command: :CONFigure:AUDSinad
Dependencies/Couplings: This key is grayed-out when opt 107 is not available.
Notes: This key invokes Audio SINAD Measurement.
Example: :CONF:AUDS
Index: n
<Mnemonic>
Results Returned
0 Returns unprocessed real trace data, as a series of comma-separated trace points, in volts.
not specified or
n = 1
Returns comma-separated scalar results, in the following order:
Return Audio SINAD (dB or % depending on Display Units)
Return Audio SINAD Ratio(–999.0 in Normal mode; in Ratio mode, dB or % depending on Ratio
Mode setting)
Ratio Reference SINAD (dB or % depending on Display Units)
Return Audio Distortion(%)
