Installation Guide 7
E444xAU Option H37 General Information
Installation Procedure
Front Panel
NOTE
Keep all of the hardware (screws, nuts, etc.) for re-use when installing the
assemblies.
1. Remove the front panel (7 screws).
2. Disconnect the green Ext Trigger Input cable on the Analog IF Assembly (P1) and the
front panel ribbon cable.
Figure 5 Front Panel
3. Remove the front panel shield (11 screws).
Figure 6 Front Panel Shield Removal
1
2
3
4
5
6
78
9
10
11
