4
E5061BEP ENA Network Analyzer – Express Configuration
The Agilent E5061BEP ENA series network analyzer express configurations are preconfigured option packages for off-the-
shelf delivery from our authorized distributors. The express configurations deliver the same specifications and functionality
as Agilent’s build-to-order instruments and also provide the same level of upgradeability, ensuring that they can evolve as
your test needs change. For more detail, visit, www.agilent.com/find/express-e5061b
Step 3. Choose hardware option (If not required, go to step 4)
Option No. Description
E5061BEP ENA Series Network Analyzer – Express Configuration
Step 3. Choose hardware option (If not required, go to step 4)
Option No. Frequency Test set Connector
Type
Impedance
analysis
Equivalent standard model
option
1
E5061BEP-115 100 kHz to 1.5 GHz Transmission/ Reflection Type-N(f) No E5061B-115/020
E5061BEP-235 100 kHz to 3 GHz S-parameter Type-N(f) No E5061B-115/020
E5061BEP-NZA 5 Hz to 3 GHz S-parameter and
Gain-phase
Type-N(f) and
BNC(f)
Yes E5061B-3L5/020 /005/720/1E5
1. Equivalent standard model options
Option 3L5 : LF-RF network analyzer with DC bias source, 5 Hz to 3 GHz
Option 020 : Standard hard disk drive
Option 005 : Impedance analysis for LF-RF network analyzer
Option 720 : Add 50 Ω resistor set
Option 1E5 : High stability time base
