Agilent N518xA, E8663B, E44x8C, and E82x7D Signal Generators Programming Guide 285
Creating and Downloading User-Data Files
Signal Generator Memory
Checking Available Memory
Whenever you download a user- data file, you must be aware of the amount of remaining signal
generator memory. Table 8- 1 shows to where each user- data file type is downloaded and from which
memory type the signal generator accesses the file data. Information on downloading a user- data file
is located within each user- data file section.
NOTE The Bit, PRAM, and State user- data (file) types only apply to the E4438C with Option 001,
002, 601, or 602, and the E8267D with Option 601 or 602.
The FIR filter, (file) types only apply to the N5182A with Option 651, 652, or 654, E4438C
with Option 001, 002, 601, or 602, and the E8267D with Option 601 or 602.
Table 8 Maximum Signal Generator Memory
Volatile (WFM1/PRAM)
Memory
Non- Volatile (NVWFM) Memory
Option Size Option Size
N5182A
651, 652, 654
a
(BBG)
a.The internal baseband generator speed upgrade Options 670, 671, and 672 are option upgrades
that require Option 651 and 652 to have been loaded at the factory (refer to the Data Sheet for
more information). Any references to 651, 652, or 654 are inclusive of 671, 672, and 674.
40 MB Standard 512 MB
019 320 MB USB memory stick user determined
E4438C and E8267D
001, 601
(BBG)
b
b. Options 001 and 002 apply to only the E4438C ESG.
32 MB Standard 512 MB
002 (BBG)
b
128 MB 005 (Hard disk) 6 GB
602 (BBG) 256 MB ---- ----
Table 8-1 User-Data File Memory Location
User- Data File
Type
Download
Memory
Access
Memory
Bit Non- volatile Volatile
Binary Non- volatile Volatile
