6-80 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362C, E8363C, E8364C
Hard Disk Drive Assembly, All Options
Parallel ATA Interface
Every PNA shipped prior to January 2009 contains the parallel ATA interface for the hard disk drive (HDD).
Starting January 2009, every PNA shipped contains the serial ATA interface for the HDD. The table below
lists the contents of the HDD with the parallel ATA interface.
Ref. Desig. Part Number Qty Description
N8982A
a
Kit (for
1.1 GHz CPU
board)
a. All new N8982A assemblies will be shipped with serial ATA hard drives and associated hardware.
Hard disk drive assembly kit with programmed hard disk drive (HDD)
(Includes A41 and items
➀
through
➆
, pre-assembled.)
A41 N5230-60048 1 Programmed hard disk drive
➀
E8364-20118 1 Hard disk drive bracket
➁
0515-0664 4 Machine screw, M3.0 x 12 pan head
➂
0515-0372 2 Machine screw, M3.0 x 8 pan head
➃
0340-1525 8 Bushing
➄
E8364-60094 1 Hard disk drive board
➅
1440-0421 1 U-handle, finger grip
➆
0515-1227 2 Machine screw, M3.0 x 6 flathead (for U-handle)
To Next Page
