Agilent Technologies E8362 Service Guide

Service Guide E8364-90038 2-9
PNA Series Microwave Network Analyzers General Product Information
E8362C, E8363C, E8364C Required Service Test Equipment
Equipment
a
Critical Specifications
Recommended
Model or Part
Number
Alternate Model
or Part Number
Use
b
Calibration and Verification Kits
Type-N calibration kit
(E8362C)
--
85054B
DC to 18 GHz
85054D
DC to 18 GHz
P,T
Ty p e- N v er ific at io n kit
(E8362C)
--
85055A
300 kHz to 18 GHz
None V
3.5 mm calibration kit
(E8362C, E8363C, E8364C)
--
85052B
DC to 26.5 GHz
85052D
DC to 26.5 GHz
P,T
3.5 mm verification kit
(E8362C, E8363C, E8364C)
--
85053B
300 kHz to 26.5 GHz
None V
2.4 mm calibration kit
(E8363C, E8364C)
--
85056A
DC to 50 GHz
85056D
DC to 50 GHz
P,T
2.4 mm verification kit
(E8363C, E8364C)
--
85057B
45 MHz to 50 GHz
None V
Cables
BNC cable (2 required) 50, length  60 cm 8120-1839 None A
3.5 mm RF cable (Qty 2)
(E8362C)
50, length  60 cm 85131C 85131E P,A,V
2.4 mm RF cable (Qty 2)
(E8363C, E8364C)
50, length  60 cm 85133C 85133E P,A,V
GPIB cable N/A 10833A/B/C/D None P,A
Adapters
3.5 mm (f) to 3.5 mm (f)
(E8362C)
Return Loss:  32 dB 83059B
85052-60012
c
P,A,T
3.5 mm (f) to type-N (m)
(E8362C)
Return Loss:  28 dB 1250-1743 None P,A,T
2.4 mm (f) to 2.4 mm (f)
(E8363C, E8364C)
Return Loss:  26 dB 11900B
85056-60007
d
P,A,T
2.4 mm (f) to type-N (m)
(E8363C, E8364C)
Return Loss:  28 dB 11903D None P,A,T
Attenuators
3.5 mm (m,f), 10-dB fixed
attenuator
(E8362C)
Accuracy: ± 0.5 dB
Freq: 10 MHz to 20 GHz
8493C
Option 010
None P
3.5 mm (m,f), 20-dB fixed
attenuator
(E8362C)
Accuracy: ± 0.5 dB
Freq: 10 MHz to 20 GHz
8493C
Option 020
None P
2.4 mm (m,f), 10-dB fixed
attenuator
(E8363C, E8364C)
Accuracy: ± 0.5 dB
Freq: 10 MHz to 40 or 50 GHz
8490D
Option 010
None P
2.4 mm (m,f), 20-dB fixed
attenuator
(E8363C, E8364C)
Accuracy: ± 0.5 dB
Freq: 10 MHz to 40 or 50 GHz
8490D
Option 020
None P
a. Unless specified otherwise, equipment listed is required for all analyzer models.
b. P = Performance tests, A = Adjustments, T = Troubleshooting, R = Repair, V = System verification
c. Included in the 85052B/D calibration kits.
d. Included in the 85056A/D calibration kits.
