4 Installation Note E8364-90024
Items Included in the Upgrade Kit
Check the contents of your kit against this list. If any item is missing or damaged, contact
Agilent Technologies. Refer to “Contacting Agilent” on page 3.
Table 1 Contents of the Upgrade Kit (E8364-60107)
Ref.
Desig.
Description Qty
Part
Number
These parts are for all analyzer options
Installation note (this document) 1 E8364-90024
Machine screw, M3.0 x 6, TORX T-10 (for attaching switch
bracket)
2 0515-0430
Machine screw, M3.0 x 12, TORX T-10 (for attaching A45 and A46
reference switches)
8 0515-0664
Switch bracket 1 E8364-00012
A23 Detector 1 5087-7242
A45, A46 Reference switch 2 5087-7238
Wiring harness, two conductors (for A45 and A46 switches) 2 8121-0966
W95 RF cable, A46 reference switch to A23 channel R1 detector 1 E8364-20119
W96 RF cable, A45 reference switch to A46 reference switch 1 E8364-20127
W97 RF cable, A46 reference switch to REFERENCE 1 SOURCE OUT 1 E8364-20121
W98 RF cable, A45 reference switch to REFERENCE 1 RCVR R1 IN 1 E8364-20123
These parts are for analyzers WITH Options 014 and 080 but WITHOUT Options UNL and 016
W67 RF cable, A25 test port 1 coupler to PORT 1 CPLR ARM 1 E8364-20156
W68 RF cable, A26 test port 2 coupler to PORT 2 CPLR ARM 1 E8364-20157
W71 RF cable, REFERENCE 2 RCVR R2 IN to A29 channel R2 mixer 1 E8364-20153
W99 RF cable, A45 reference switch to A28 channel R1 mixer 1 E8364-20152
These parts are for analyzers WITH Options UNL, 014, and 080 but WITHOUT Option 016
W71 RF cable, REFERENCE 2 RCVR R2 IN to A29 channel R2 mixer 1 E8364-20155
W99 RF cable, A45 reference switch to A28 channel R1 mixer 1 E8364-20154
This part is for analyzers with Options UNL, 014, 016, and 080
W99 RF cable, A45 reference switch to A28 channel R1 mixer 1 E8364-20125
