Getting Started Power Meter and Sensor Capability
14 EPM-P Installation Guide
Power Meter and Sensor Capability
Your E4416A or E4417A power meter is compatible with Agilent
E-Series
E9320, E-Series E9300, E-Series E4400, 8480 Series and N8480
Series power sensors. However, not all sensor and meter combinations have the
same features or capabilities. The main differences are:
1
Not applicable for N8480 Series power sensors with Option CFT
Specifications
The specifications for the power meter are listed in the E4416A and E4417A
user’s guide.
Features
E-Series
E9320
E-Series
E9300
E-Series
E4400
8480
Series
N8480
Series
Average Power of CW Signal • • • • •
Cal Factors on EEPROM • • • •
1
>200 Readings/sec. • • •
Average Power of modulated signal • • •
Peak Power •
Rising Edge Trigger •
Falling Edge Trigger •
