Timebase = 10.0 ns/div Risetime = 4.9 ns
Carrier Frequency = 10.0 GHz Falltime = 2.05 ns
I
Figure 1-19.
pk61 Sab
Typical Pulse Modulation Envelope Illustrates the l%st Rise
and
JMl
Times,
Excellent Flatness and Pulse Fidelity
Internal Pulse Source
Pulse Source Modes: kee-run, triggered with delay, doublet and gated. Triggered with
delay, doublet and gated require external trigger source.
Pulse Repetition
Frequency:
3 Hz to
>3
MHz
Pulse Repetition Interval (PRI):
300
ns to 419 ms
Pulse Width
(T,):
25 ns to 419
ms
Variable Pulse Delay (free-run mode,
Td):
k419 ms from sync pulse to video modulation
Variable Pulse Delay (triggered with delay
&
doublet modes,
Td):
225
ns
to 419 ms with
f25
ns jitter
Pulse
Width/Delay/PRI
Resolution: 25
ns
Pulse
Delay
(Video
to
m
Tnr):
Nomiruzll~
~20
ns,
1 to
20
GI%
l-18
HP83731A/32ASpscifications
