Peak Power Level = II dBm
-5.00
0 5 10 15 20 25 30 35 u) 45 50 55 60
Desired Log AM Depth (attenuation) in dB
Figure l-20.
Typical Log AM Error (deviation from desired depth) at 25OC for Carrier Frequencies
between 1.0 and 20 GHz
Simuitaneous Modulations
Full AM bandwidth and depth is available at any pulse rate or width. FM is completely
independent of AM and pulse modulation.
l-20 HP83731Al32ASpecifications
