18-6

Measure Commands

AMPLitude:ISIVsbit:BITS?

tude:UNITs” on page 18-11. Use the query “SINTegrity:PATTern?” on page 18-41 to return

the corresponding bit sequence. Use the query “AMPLitude:ISIVsbit:BITS?” on page 18-6 to

return a list of corresponding bits for which AMPLitude:ISIVsbit? has returned values.

Restrictions 86100C (software revision A.07.00 and above) with Jitter Mode including Advanced Ampli-

tude Analysis/RIN/Q-Factor application.

Example 10 OUTPUT 707;”:MEASURE:AMPLITUDE:ISIVSBIT?”

Returned Format [:MEASure:AMPLitude:ISIVsbit] <block data><NL>

AMPLitude:ISIVsbit:BITS?

Query MEASure:AMPLitude:ISIVsbit:BITS?

Returns definite-length block data. The data block contains the list of bits for which AMPLi-

tude:ISIVsbit? has returned values. Each bit value is a 32-bit integer (4 bytes). The data block

is followed by a linefeed termination character (0A hex).

Restrictions 86100C (software revision A.07.00 and above) with Jitter Mode including Advanced Ampli-

tude Analysis/RIN/Q-Factor application.

Example 10 OUTPUT 707;”:MEASURE:AMPLITUDE:ISIVSBIT:BITS?”

Returned Format [:MEASure:AMPLitude:ISIVsbit:BITS] <block data><NL>

AMPLitude:ISIVsbit:HIGHest?

Query MEASure:AMPLitude:ISIVsbit:HIGHest? {ONE | ZERO}

Returns highest amplitude bit (for a one or zero level) for which AMPLitude:ISIVsbit? has

returned values. The bit value is a 32-bit integer (4 bytes).

Restrictions 86100C (software revision A.07.00 and above) with Jitter Mode including Advanced Ampli-

tude Analysis/RIN/Q-Factor application.

Example 10 OUTPUT 707;”:MEASURE:AMPLITUDE:ISIVSBIT:HIGHEST?”

Returned Format [:MEASure:AMPLitude:ISIVsbit:HIGHest] <integer><NL>

AMPLitude:ISIVsbit:LOWest?

Query MEASure:AMPLitude:ISIVsbit:LOWest? {ONE | ZERO}

Returns lowest amplitude bit (for a one or zero level) for which AMPLitude:ISIVsbit? has

returned values. The bit value is a 32-bit integer (4 bytes).

Restrictions 86100C (software revision A.07.00 and above) with Jitter Mode including Advanced Ampli-

tude Analysis/RIN/Q-Factor application.

Example 10 OUTPUT 707;”:MEASURE:AMPLITUDE:ISIVSBIT:LOWEST?”

Returned Format [:MEASure:AMPLitude:ISIVsbit:LOWest] <integer><NL>

AMPLitude:LEVel:CIDigits:LAGGing

Command MEASure:AMPLitude:LEVel:CIDigits:LAGGing <num_digits>

Specifies the minimum number of lagging consecutive identical digits to be uses in defining

the one and zero levels.
