Getting Started 1
N1913/1914A Installation Guide 17
2 Connect the other end of the 11730A cable to the CHANNEL A (or CHANNEL B) input
connector.
3 Confirm a reading sensor pop-up message appears briefly.
4 Confirm the display has changed to a measurement reading.
This message does not appear when
connecting an 8480 Series power
sensor.
Diagram shows display with
an E-Series E4413A power
sensor connected.
Dual Channel
