Agilent Technologies PSG Series Installation Notes

3
PSG Series Signal Generators E8241A, E8244A, E8251A, and E8254A
Add Option 1E1 (Attenuator) Upgrade Kit Part Number:
E8251-60088
Introduction
This upgrade kit adds Option 1E1 (Attenuator) to the:
• 250kHz to 20GHz PSG-L Series CW E8241A
• PSG-A Series Analog E8251A
• 250kHz to 40GHz PSG-L Series CW E8244A
• PSG-A Series Analog E8254A.
Installation includes the following major steps:
1. Remove the instruments covers.
2. Install the attenuator hardware for Option 1E1.
3. Access the Agilent PSG webpage to activate Option 1E1.
4. Re-assemble the signal generator.
Product Affected: . . . . . . . . . . . . . . . . . . . . . . . . . E8241A, E8244A, E8251A, and E8254A
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . All
Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (X) Agilent Technologies Service Center
( ) Personnel Qualified by Agilent Technologies
( ) Customer
Estimated Installation Time: . . . . . . . . . . . . . . . 1.5 hours
Estimated Verification Time: . . . . . . . . . . . . . . . E8241A/51A = 8.0 hours
E8244A/54A = 15.0 hours
