Installation Kit Parts List
Tools Required
• TORX T-10 driver
• TORX T-15 driver
• TORX T-20 driver
• 5/16” Open ended wrench
•Long nose pliers
•Scissors
Safety Considerations
WARNING Before you disassemble the instrument, turn the power switch off and
unplug the signal generator. Failure to unplug the signal generator can
result in personal injury.
CAUTION Electrostatic discharge (ESD) can damage or destroy electronic components. All
work on electronic assemblies should be performed at a static-safe workstation.
Item Quantity Description Part Number
1 1 Attenuator 115dB E8251-60070
2 1 Semi Rigid Cable (40GHz) E8251-20025
3 1 Semi Rigid Cable (20GHz) E8251-20026
4 1 Semi Rigid Cable (20GHz) E8251-20027
5 1 Semi Rigid Cable (40GHz) E8251-20028
6 2 Mounting Screw 0515-1035
7 1 Label 7120-1232
8 1 Installation Note E8251-90045
