Natural gas conversion must be performed only by your natural gas provider or service company.
1. Disconnect the regulator hose from the gas valve. See Figure 14.
Figure 13
Serial Number Model Number: 99000
CAUTION: The gas pressure regulator provided with this appliance must be used. This regulator is
set for an outlet pressure of 11 inches water column (2.7 kPa). The gas supply must be turned off
at the LP-gas supply cylinder when this appliance is not in use.
This appliance has been converted to use Natural Gas.
Input 40,000 Btu/hr.
Max Gas Supply Pressure 7 inch w.c. (12.2 kPa) Min Gas Supply Pressure 5 inch w.c. (1.24 kPa)
FOR OUTDOOR USE ONLY. If stored indoors, detach and leave cylinder outdoors.
Make sure the control knob is in the "OFF" position.
Unscrew the push button cap on the ignition module
located on the control panel to access the battery
compartment. The ignition module requires one
Alkaline AAA size battery (1.5V). The negative (-) end goes
in first. See Figure 15. Dispose of battery safely. May explode or leak
if charged or disposed of in fire. Make sure of the polarity. Mercury and cadmium free.
Warning: If these instructions are not followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
1. Make sure the control knob is in the "OFF" position. Open the tank valve all the way. See Fig. 16.
Figure 15 CONTROL KNOB
2. Push in the igniter button. You will hear a slight clicking sound. With the igniter button pushed in,
push and turn the control knob to the “ON” position.the fire should light within a few
seconds. Once the flame is lit, release the igniter button and continue to hold the control knob in
for 10 to 15 seconds. Release the control knob. The control knob should pop back out and then
remain lit.
Note: If the fire does not light, turn the knob to the “OFF” position and wait five (5) minutes
before trying again.
3. To turn down the flame, push the control knob in slightly and turn to Medium (medium flame),
or Low (small flame).
4. To shut down the fire pit, turn the control knob to the “OFF” position and turn off the tank valve.
