Parts List
NO. Parts Name Q'ty
1 O-RING (Ø45x1.5) 1
2 ANTI-SEIZE RING 1
3 O-RING (Ø32x1.5) 4
4 THRUST RING (3252) 1
5 ANTI-SEIZE CUP 1
6 DOWEL PIN (Ø4x11.8) 2
7 SOCKET CAP SCREW (M5-0.8 x 55) 4
8 WATER FEED HOUSING 1
9 ELBOW FITTING (PT1/4" x 3/8"U) 1
10 OIL SEAL (Ø40xØ52x7) 1
11 OIL SEAL (Ø40xØ50x7) 1
12 STAINLESS BUSHING 1
13 OUTPUT SPINDLE 1
14 PARALLEL KEY (6x6x20) 2
15 BALL BEARING (6206) 2
16 EXTERNAL CIRCLIP (S-30) 1
17 OIL SEAL (Ø30xØ55x7) 1
18 OUTPUT GEAR 1
19 NYLOOK NUT (M20xP1.5) 1
20 PARALLEL KEY (4x4x30) 1
21 OIL IMPELLER 1
22 EXTERNAL CIRCLIP (S-18) 1
23 NEEDLE BEARING (TA1815) 1
24 SOCKET CAP SCREW (M6-1.0 x 30) 12
25 SPRING WASHER (M6) 12
26 FLEXIBLE COOLANT NOZZLE (Ø6.4xØ10x0.12M) 1
27 FITTING (1/4"M x Ø10) 1
28 GEAR HOUSING 1
29 BALL BEARING (6201) 3
30 CLUTCH PINION(M1.5x20T) 1
31 PRESSURE DISC (Ø20.1xØ43x3) 3
32 BELLEVILLE SPRING 3
33 CLUTCH BRASS DISC (Ø20.1xØ41x2) 4
34 CLUTCH STEEL PLATE 3
35 INPUT GEAR (M1.25x51T) 1
36 HEX NUT (M16) 1
37 BALL BEARING (6203) 1
38 COUNTERSHAFT (M1.75x14T) 1
NO. Parts Name Q'ty
39 PARALLEL KEY (6x6x15) 2
40 LAY GEAR (M1.5x40T) 1
41 EXTERNAL CIRCLIP (S-20) 1
42 GEAR CASE GASKET 1
43 GEAR PLATE 1
44 SOCKET SET SCREW (M8x7xP1.25) 1
45 O-RING (Ø105xØ109x2) 2
46 O-RING (Ø84xØ88x2) 2
47 O-RING (Ø76xØ80x2) 2
48 MOTOR HOUSING 1
49 STATOR ASSEMBLY 1
50 OIL SEAL (Ø15xØ25.5x4.6) 1
51 ARMATURE ASSY. 1
52 MOTOR END CASTING 1
53 WATER FEED CONNECTOR KIT 1
54 SOCKET SET SCREW-SUS (PT1/4") 1
55 O-RING (Ø7.8x1.3) 2
56 O-RING (Ø4.5x1) 4
57 ELECTRONICS COVER 1
58 SOCKET CAP SCREW (M4-0.7 x 16) 4
59 ELECTRONICS UNIT 1
60 PANHEAD TAPPING SCREW (M4x30) 20
61 FLAT WASHER (Ø4xØ10x1) 5
62 SOCKET CAP SCREW (M4-0.7 x 40) 5
63 PANHEAD TAPPING SCREW (M4x8) 4
64 LCD DISPLAY 1
65 POWER SUPPLY CABLE (VDE-1.5x3Cx3.5M-H07RNF) 1
66 STRAIN RELIEF GLAND 1
67 TAIL COVER (GRAY-RAL7016) 1
68 LED OVERLOAD LAMP (110V&220V) 1
69 PROTECTION FRAME 1
70 HANDLE RETAINER 1
71 HANDLE RETAINER 2
72 SOCKET CAP SCREW (M5-0.8 x 20) 2
73 EARTHING MARKING 1
74 EXTERNAL STAR WASHER (M5) 1
77 EXTENSION SPACER 1
79 OIL SEAL (Ø40xØ55x7) 1
