7
COOLING: The automatic through-the-spindle cooling function is only effective when using annular cutters.
When tapping or using twist drills, cutting oil must be added manually.
SETTING UP FOR TAPPING
CAUTION: Never use a cutting tool which is larger than the maximum rated capacity of the machine.
CAUTION: Always follow the tap manufacturer’s recommendation for selecting the correct size hole for
tapping.
CAUTION: Never attempt to change gears on a running machine! Only change gears when the
machine is at rest.
1. For tapping, select the universal tap chuck. or, if you are using an outside sourced tap collet or quick
1. Large Range Clamp Collet (Not Included)
2. Universal Tap Chuck
3. Tap (Not included)
4. Coolant Feed Spring And Seal
5. Pilot Pin (Not included)
6. Annular Cutter Arbor 3/4" (19.05mm)Weldon Shank )
7. Annular Cutter (Not included)
8. 1/2" Twist Drill Chuck
9. Drill Chuck Arbor
10. Quick-Release Collar2
1
8
3
4
5
6
7
9
10
2
3
