Installation-, Operating-, Maintenance-Manual, Spare part List MAK10
AGT-PSG GmbH & Co.KG
Errors and printing mistakes excepted
Page 47
Translation - Manual MAK10 Rev. 11/2017
Technical Data
Model-Specific Data
Model
Type MAK10-1101-4-00-X MAK10-1101-4-10-X
Number of gas paths 1 1
Number of condensate pumps 1 1
Number of pre-separators - -
Number of teflon filtes - 1
Number of flowmeters - -
Number of electronic controls - -
Operation data
Gas flow per gas path at 65°/55°tp 125Nl/h 2.0lpm / 175Nl/h 2.9lpm
Ready for start-up < 5min
Design data
Dimensions (BxHxT) 310mm x 266mm x 321mm
Weight without options 16,8kg 17,1kg
Electrical data
Power consumption 220W (ta=45°C)
Model
Type MAK10-1101-4-11-X MAK10-1101-4-1F-X
Number of gas paths 1 1
Number of condensate pumps 1 1
Number of pre-separators - -
Number of teflon filtes 1 1
Number of electronic controls 1 1
Number of flowmeters - 1
Operation data
Gas flow per gas path at 65°/55°tp 125Nl/h 2.0lpm / 175Nl/h 2.9lpm
Ready for start-up < 5min
Design data
Dimensions (BxHxT) 310mm x 266mm x 321mm
Weight 17,3kg 17,4kg
Electrical data
Power consumption 220W (ta=45°C)
General Data
Operation data
Gas temperature at inlet max. 140°C
Ambient temperature 5-45°C
Operating pressure (abs.) 0.5-2.2bar
Gas dew-point at outlet 3.0°C +/-0.3°C
Pressure loss per gas path 5mbar (V=125Nl/h)
Dead space per gath path 26 ml
Material of gas paths
Cooling transfer tube Aluminium
Surface / Housing / Sealings PTFE-Coating / PVDF Housing / Viton Sealings
Design data
Connections Gas: PVDF DN 4/6 / Condensate: PVDF DN 4/6
Approvals CE / cMETus
Electrical data
Mains connection / power supply Plug / 230V 50/60Hz +/-15% / 115V 50/50Hz +/-10%
Communication / Alarm set points Potential-free alarm-contact / < +2.0°C / > +10.0°C
Housing protection class IP 20 EN 60529 / EN 61010
