Ai-Thinker ESP32-A1S User Manual

ESP32-A1S Specification V2.3
Copyright © 2021 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 9 of 20
2.4. Bluetooth（BR）RF performance
List 4 Main parameter description
Description
Typical
Unit
Output Power
Transmit power
Typical 8±2
dBm
Receiving sensitivity Bluetooth low energy 1M
Sensitivity@0.1%BER
≤-89
dBm
2.5. Bluetooth（EDR）RF performance
List 5 Main parameter description
Description
Typical
Unit
Output Power
Transmit power
Typical 8±2
dBm
Receiving sensitivity Bluetooth low energy 1M
Sensitivity@0.01%BER
≤-89
dBm
2.6. BLE RF performance
List 6 Main parameter description
Description
Typical
Unit
Output Power
Transmit power
Typical 8±2
dBm
Receiving sensitivity Bluetooth low energy 1M
Sensitivity@30.8%PER
≤-94
dBm
2.7. Power consumption
The following power consumption data is based on 3.3V power supply, 25°C
