Before the installaon, please take away the
Harness system of baby car seat.
Note: The Baby insert, Harness strap, Harness
buckle, Buckle pads& Shoulder pads should be
stored away safely for future use ( see 5.1
Removing the 5-point harness system and cover ).
4.2 Installaon of Group II/III and it is for the children
whose weight between 15-36kg.
5
Pull the 3 point belt (lap and shoulder belt)
through belt guide slot at the car seat base
and back part of the car seat, please confirm
seat belt lays flat and is not twisted. Choose
proper height of shoulder belt slot at the
back part of the car seat to fit child’s body.
Put the two buckle clips together then fasten
buckle and harness clips unl you hear a
noce able “click”.
11 12
Installaon in the vehicle
Care instrucons
5.1 Removing the 5-point harness system and cover
Pull two harness straps out
off cover slot.
Loose the harness strap
and pull strap out off the
strap yoke as shown in
right picture.
Aer above steps, draw whole
strap out from the boom of
seat. Rotate buckle clip to the
shown posion, then take it out
from seat base.
Remove the 5-point harness
system then remove the
headrest cover and the shell
cover.
4.3 Installaon of Group II/III without backrest and it is
for the children whose weight between 15-36kg.
Hold the backrest, then push it over toward
the level.
Press the base with your hand, and pull the
backrest out from base with your other hand.
Place the child car seat on the passenger seat
ensuring it is firmly against the vehicle seat.
Sit your child on the car seat with their back
against the back rest.
Place the seat belt around your child
posioning th lap secon of the safety belt
under both armrests, then harness clips unl
you hear a noce able “click”.
5.2 Refing the 5-point harness system and cover
To refit the 5-point harness system, please refer to the steps how to take
off it then do as the reverse way.
