Lifting or Lowering the Bed Legs:
18. Ensure there are no encumbrances on the bed legs
19. Press and hold the bed lower button on the handset
20. The bed legs will lift up to the bed frame
21. If the bed castors shift into a vertical position, stop the lift, adjust them
manually to be parallel with bed frame, then continue the lift until bed legs
are fully lifted into the bed frame – as if the bed was fully lowered in the flat
position on the ground
22. Disconnect the mains power lead, gather and secure with Velcro
23. Repeat the above steps in reverse to lower the legs to the ground
in preparation to remove the EasyMove Transport System
Pivoting the Bed Frame:
24. Disengage the pivot lock on each EasyMove trolley by pulling and twisting
25. Gently pivot the bed on its axis by hand until vertical. This is a very easy
motion requiring little force
26. If more than one hand is required there is likely to be an encumbrance
on the pivot motion, please check around the bed
27. When the bed frame is vertical, re-engage the pivot locks by pulling and twisting
28. Repeat the above steps in reverse to reposition the bed surface horizontally
in preparation for lowering
Moving the Bed with the EasyMove Transport System:
29. The EasyMove Transport system can be manoeuvred by a single person,
or two people
30. Ensure power, handset and any other leads are all secured and out of the way
31. If one person is moving the bed, engaging the directional locking
castors on the forward of the two EasyMove trolleys will allow better control
and manoeuvrability
32. If two people are moving the bed then using the directional castors is less
necessary so they may remain disengaged
33. Using the trolley handles, push the trolley forward from the rear proceeding
at an even pace
When the EasyMove Transport System is loaded but stationery or
not in use, the total locking castors should remain locked at all times
(red locking button).
