Aidcall Touchsafe Pro Maxpage - Maxpage Kit

DocNo.FM5611issueCPage5

5. MAXPAGEKIT

TheMaxpagekit(AidcallPartNo.E40119)includestheMaxpageTerminal&Antenna,minikeyboard,
12V/3Aboxedpowersupply,12V/7Ahrechargeablebattery,mainslead,lowvoltagepowerleadanda
serialdatalead.Note:theplug‐topPSUalsointhekitisnotused.








































TRANSMITTERLED’s


TheREDPOWERLEDshouldbepermanentlyilluminatedwhenthe12VPSUisconnected.
TheGREENTRANSMITTINGLEDwillonlyilluminatewhenasignalistransmittedtothePagers.

POWERSUPPLYLED’s


TheGREENPOWERLEDshouldbepermanentlyilluminatedwhentheMainssupplyishealthy.
TheREDFAULTLEDwillilluminateifthe12Voutputorbatteryfusehasblown.

WhipAntenna(120mmhigh)
withBNCConnector
Red PowerLED
DesktopEnclosure
226x160x70mm(LxWxH)
GreenTransmittingLED
WallMountedEnclosure
200x230x80mm(HxWxD)
12V7Ah
RechargeableBattery
2mMainsLead
Green PowerLED
Red FaultLED
MaxpageTerminal&Antenna
12V/3APowerSupply
HingedLid(1ScrewFixing)
2Line/16Character
BacklitLCDDisplay
BacklitKeyboard
RearPower&DataSockets
PS/2MiniKeyboard
1.5mPower Lead1.8mDataLead
