19 Specifications
ACCURACY
Accuracies apply for 1 year 19°C to 25°C. Temperature coefficient outside these limits is <0.1 x
quoted range accuracy per °C.
DC Volts
Range Accuracy Resolution Input Impedance
100mV 0.02% ± 3 dig. (after null) 1uV
10.11M
:
1000mV 0.02% ± 3 dig. 10uV
10.11M
:
10V 0.02% ± 3 dig. 100uV
10.0M
:
100V 0.02% ± 3 dig. 1mV
10.1M
:
1000V 0.02% ± 3 dig. 10mV
10.11M
:
Typical Input
Impedance:
10M://<1000pF, except for Vdc plus Vac measurement when the
1M: ac attenuator is in parallel with the 10M: dc attenuator.
Maximum Input: 1kV DC or AC peak, any range.
NMR: >60dB at 50/60Hz.
1k: Unbalanced CMR:
>90dB at DC/50Hz/60Hz.
Recommended maximum peak AC plus DC voltage while measuring DC voltage
These values only apply when the DC component does not exceed the range maximum and the
analogue 50/60Hz rejection filter is enabled.
AC Volts (True RMS)
Range Accuracy Resolution
45Hz - 10kHz 10kHz - 30kHz 30kHz - 50kHz
100mV 0.2% ± 150 dig 1.5% ± 200 dig. - 1µV
1000mV 0.2% ± 100 dig 0.5% ± 100 dig 2% ± 200 dig 10µV
10V 0.2% ± 100 dig 0.5% ± 100 dig 2% ± 200 dig 100uV
100V 0.2% ± 100 dig 0.5% ± 100 dig 2% ± 200 dig 1mV
750V 0.2% ± 100 dig 0.5% ± 100 dig 2% ± 200 dig 10mV
Accuracy specifications apply for readings between 10,000 and 120,000 counts. Maximum crest
factor = 3 at nominal range maximum.
Input Impedance:
1M://<1000pF
Maximum Input: 750V rms, 1000V peak; any range.
1k: Unbalanced CMR:
>60dB at DC/50Hz/60Hz
(AC + DC) Voltage Accuracy
Total measurement error will not exceed the sum of the separate ac and dc accuracy specifications
plus 10 display counts.
Range
AC
pk
+DC
Range
AC
pk
+DC
The table shows the maximum peak AC
(45Hz-50kHz) plus DC voltage that can be
applied without affecting the accuracy of the
DC measurement due to overload clamping.
100mV, 1000mV 1.8V 100V 180V
10V 18V 1000V 1000V
