Page 51
Frequency
Range Accuracy Resolution
100Hz 0.01Hz
1000Hz 0.01% ± 1 dig. 0.1Hz
10kHz 1Hz
100kHz 10Hz
Accuracy specifications for 100Hz range apply only at slow measurement speed of 4 readings
per second.
Range: 10Hz to 100kHz
Input sensitivity:
Better than 30mVrms (100mV range); better than 10% of range for
all other Vac and Iac ranges.
Capacitance
Scale length: 1200 counts
Range Accuracy Resolution
10nF 10pF
100nF 2% ± 5 dig. 100pF
1uF 1nF
10uF 10nF
100uF 5% ± 5 dig. 100nF
Temperature
Linearised measurement for PT100 or PT1000 RTD probes, 2-wire or 4-wire
measurement display in ºC or ºF.
RTD Range Accuracy Resolution
PT100 -50 to 400°C 0.05% ± 0.5°C 0.1°C
PT1000 -50 to 400°C 0.05% ± 0.5°C 0.1°C
Accuracy specifications apply to multimeter only, they do not account for additional probe accuracy
errors.
Continuity and Diode Test
Continuity:
1000: range selected; audible tone sounds for impedance <10:.
Diode Test: Test current approximately 1mA; displays voltages up to 1.2V.
Maximum Open Circuit
Voltage:
3.5V
Maximum Input: 1000V DC or AC rms, any range.
TRIGGER
External Remote Trigger (TTL/CMOS)
Connection: Terminal block on rear panel.
Input:
Input to the LED of an opto-isolator through 1k:resistor. Apply >+3V
to trigger remote input. Max. Voltage 10V.
Output:
Opto-isolated open collector output, conducts for 250ms on
completion of input trigger. Max. off-state Voltage: 10V. On state sink
current 2mA (typical).
