L4 BASS PREAMP 7
PARTS LIST, CONT.
PART VALUE TYPE NOTES
R70 3k3 Metal film resistor, 1/4W
R71 33k Metal film resistor, 1/4W
R72 10k Metal film resistor, 1/4W
R73 10k Metal film resistor, 1/4W
R74 47k Metal film resistor, 1/4W
R75 47k Metal film resistor, 1/4W
R76 100k Metal film resistor, 1/4W
R77 100k Metal film resistor, 1/4W
R78 10k Metal film resistor, 1/4W
R79 22k Metal film resistor, 1/4W
R80 10M Metal film resistor, 1/4W
R81 2k7 Metal film resistor, 1/4W
RPD1 2M2 Metal film resistor, 1/4W Ch. 1 input pulldown resistor. Can be as low as 1M.
RPD2 2M2 Metal film resistor, 1/4W Ch. 2 input pulldown resistor. Can be as low as 1M.
LEDC 10k Metal film resistor, 1/4W Channel 1 LED current-limiting resistor.
LEDD 10k Metal film resistor, 1/4W Channel 2 LED current-limiting resistor.
LEDR 10k Metal film resistor, 1/4W Bypass LED current-limiting resistor.
C1 220n Film capacitor, 7.2 x 2.5mm
C2 22pF MLCC capacitor, NP0/C0G
C3 22uF Electrolytic capacitor, 5mm
C4 10n Film capacitor, 7.2 x 2.5mm
C5 2n7 Film capacitor, 7.2 x 2.5mm
C6 470n Film capacitor, 7.2 x 3mm
C7 15n Film capacitor, 7.2 x 2.5mm
C8 68n Film capacitor, 7.2 x 2.5mm
C9 22pF MLCC capacitor, NP0/C0G
C10 220pF MLCC capacitor, NP0/C0G
C11 100n Film capacitor, 7.2 x 2.5mm
C12 4.7uF Electrolytic capacitor, 4mm
C13 220pF MLCC capacitor, NP0/C0G
C14 100n Film capacitor, 7.2 x 2.5mm
C15 1n Film capacitor, 7.2 x 2.5mm
C16 4.7uF Electrolytic capacitor, 4mm
C17 15n Film capacitor, 7.2 x 2.5mm
C18 68n Film capacitor, 7.2 x 2.5mm
C19 4.7uF Electrolytic capacitor, 4mm
C20 82n Film capacitor, 7.2 x 2.5mm
