L4 BASS PREAMP 8
PARTS LIST, CONT.
PART VALUE TYPE NOTES
C21 82n Film capacitor, 7.2 x 2.5mm
C22 3n3 Film capacitor, 7.2 x 2.5mm
C23 10n Film capacitor, 7.2 x 2.5mm
C24 150n Film capacitor, 7.2 x 2.5mm
C25 2.2uF Film capacitor, 7.2 x 5mm Original amp uses 2.7uF tantalum, but 2.2uF film will work the same.
C26 220pF MLCC capacitor, NP0/C0G
C27 330n Film capacitor, 7.2 x 2.5mm
C28 68n Film capacitor, 7.2 x 2.5mm
C29 2.2uF Film capacitor, 7.2 x 5mm
C30 100pF MLCC capacitor, NP0/C0G
C31 10uF Electrolytic capacitor, 5mm
C32 100n MLCC capacitor, X7R
C33 100n MLCC capacitor, X7R
C34 100n MLCC capacitor, X7R
C35 100n MLCC capacitor, X7R
C36 22uF Electrolytic capacitor, 5mm
C37 22uF Electrolytic capacitor, 5mm
C38 22uF Electrolytic capacitor, 5mm
C39 22uF Electrolytic capacitor, 5mm
C40 22uF Electrolytic capacitor, 5mm
C41 22uF Electrolytic capacitor, 5mm
C42 22uF Electrolytic capacitor, 5mm
C43 22uF Electrolytic capacitor, 5mm
C44 100n MLCC capacitor, X7R
C45 100uF Electrolytic capacitor, 6.3mm
C46 47uF Electrolytic capacitor, 5mm
D1 1N5817 Schottky diode, DO-41
D2 1N457A Rectifier diode, DO-35
D3 1N457A Rectifier diode, DO-35
D4 1N457A Rectifier diode, DO-35
D5 1N457A Rectifier diode, DO-35
D6 1N914 Fast-switching diode, DO-35
D7 1N914 Fast-switching diode, DO-35
D8 1N4004 Rectifier diode, DO-41
D9 1N4004 Rectifier diode, DO-41
Z1 1N4742A Zener diode, 12V, DO-41
Q1 2N5088 BJT transistor, NPN, TO-92
