- 24 -
TECHNICAL PRECAUTIONS
• Operating temperature: Entrance station: -10 °C to +60 °C (+14 °F to +140 °F)
Security guard station: 0 °C to +40 °C (+32 °F to +104 °F)
• Mounting location: Do not install the entrance station in a place where there would be a bright light behind a visitor (or where there would be
a bright background) or in a place where the camera lens would be directly exposed to sunlight or a bright light.
Entrance stations (integrated type) have a built-in people sensor, so do not place objects in places monitored by the people
sensor. Also, placing the unit in very bright sunlit areas may prevent the sensor from working properly.
• Rain hood (option): Although the entrance station is weather resistant, it is recommended that it not be directly exposed to weather conditions.
The rain hood can be installed to protect the entrance station from rainfall.
• Post-replacement setup: After all wiring is completed and the residential station has been replaced, turn off the power to the GT-BC temporarily and
then turn it back on. Next, reprogram the relevant residential station.
• Operation: When an entrance station is calling a residential station, the call tone from the doorbell button will not sound.
• Cleaning: Clean the units with a soft cloth dampened with a neutral household cleanser. Do not use any abrasive cleaner or cloth.
• Repair requests: If there is a system malfunction, unplug the power supply and contact a qualified technician for service.
7
TECHNICAL PRECAUTIONS
8
SPECIFICATIONS
GT-DA-L/GT-DA
• Dimensions: 93 (H) × 108 (W) × 49 (D) (mm)
3-5/8 (H) × 4-1/4 (W) × 1-7/8 (D) (inches)
• Weight: GT-DA-L: Approx. 160 g (0.35 lbs.)
GT-DA: Approx. 150 g (0.33 lbs.)
GT-VA
• Imaging element: Complementary metal oxide semiconductor (CMOS)
• Dimensions: 93 (H) × 108 (W) × 56.5 (D) (mm)
3-5/8 (H) × 4-1/4 (W) × 2-1/4 (D) (inches)
• Weight: Approx. 140 g (0.31 lbs.)
GT-NS-V/
GT-NS
• Power supply: DC 24 V (supplied from PS-2420 etc)
• Current consumption : 90 mA
• Dimensions: 90.5 (H) × 106 (W) × 48.5 (D) (mm)
3-5/8 (H) × 4-1/8 (W) × 1-7/8 (D) (inches)
• Weight: Approx. 150 g (0.33 lbs.)
GT-10K
• Dimensions: 90.5 (H) × 106 (W) × 42.5 (D) (mm)
3-5/8 (H) × 4-1/8 (W) × 1-5/8 (D) (inches)
• Weight: Approx. 90 g (0.2 lbs.)
GT-SW
• Dimensions: 90.5 (H) × 106 (W) × 42.5 (D) (mm)
3-5/8 (H) × 4-1/8 (W) × 1-5/8 (D) (inches)
• Weight: Approx. 90 g (0.2 lbs.)
GT-AD
• Dimensions: 90.5 (H) × 106 (W) × 42.5 (D) (mm)
3-5/8 (H) × 4-1/8 (W) × 1-5/8 (D) (inches)
• Weight: Approx. 90 g (0.2 lbs.)
GT-DMV/GT-DM
• Power supply: DC 24 V (supplied from PS-2420 etc)
•
Current consumption : 90 mA
• Video monitor: 3-1/2" color LCD
• Imaging element: Complementary metal oxide semiconductor (CMOS)
• Dimensions: 410 (H) × 150 (W) × 68 (D) (mm)
16-1/8 (H) × 5-7/8 (W) × 2-5/8 (D) (inches)
• Weight: Approx. 3 kg (6.61 lbs.)
GT-MK
• Power supply: DC 24 V (supplied from PS-2420 etc)
•
Current consumption: 100 mA
• Dimensions: 210 (H) × 215 (W) × 69 (D) (mm)
8-1/4 (H) × 8-1/2 (W) × 2-3/4 (D) (inches)
• Weight: Approx. 900 g (1.98 lbs.)
