Aiphone IX SERIES Programming Guide

For more details about the features and information above, please contact Technical Support.For more details about the features and information above, please contact Technical Support.
Adding IX-SOFT to Support Tool (Continued)
Pg. 11
Step 5: SIF Settings (IX-SOFT Licensing)
Click the Station View button at the top of the screen. From the left hand side menu, expand Function Settings and select SIF.
Under the Select Station to Edit section, use the drop-down menu to select the added IX-SOFT station and click Select .
Program Type: 1111
IPv4: Static IP Address of the IXW-MA-SOFT device
Destination Port: 65060
SSL: Enabled
Connection: Socket
Under the SIF section, station information of the IXW-MA-SOFT will need to be added to the SIF settings of each IX-SOFT instance.
Fill in #01 for each IX-SOFT station with the following settings.
Transmission Trigger
Scroll down to transmission trigger under the SIF settings and for #01 select the check box for "initialization notice"
Scroll DownScroll Down
Aiphone Corporation
|
www.aiphone.com
|
(800) 692-0200

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
