Aiphone IX SERIES Programming Guide

For more details about the features and information above, please contact Technical Support.
Pg. 8
Use the drop-down menu under Output Time Range to select
either 200-2000(msec) or 3-600(sec), then use the Output Time
section to enter the desired value.
Output Time Range and Output Time
Click the Update button save
the changes.
Update
Door Release Timer Settings
Getting Started
The amount of time the relay output activates on the IXW-MA is determined by the Output Time Range set for the door station
interacting with it. If the door station's Output Time Range is set to 3 seconds, for example, the IXW-MA output it is assigned to will
also activate for 3 seconds.
To adjust the amount of time the door release relay output activates, expand Relay Input / Relay Output Settings and click Relay
Output.
Scroll RightScroll Right
Relay Output Settings
Aiphone Corporation
|
www.aiphone.com
|
(800) 692-0200

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
